Product Overview
Cleanroom Ceiling Light for tri-proof & cleanroom lighting: 20-80W, 120lm/w, AC100-277V. B2B selection and project support from Yaoqian.
Technical Parameters
| Power | 20-80W |
|---|---|
| LED chip | Project-specific |
| Efficacy | 120lm/w |
| CRI | 80 |
| Input voltage | AC100-277V |
| CCT | 3000-6500K |
| Operating temperature | -20 deg C-+45 deg C |
| Beam angle | 110° |
| Category | Project-specific |
Engineering Selection Points
Application Fit
For damp, dusty, food, pharma, electronics, parking, equipment rooms and washdown areas. Tri-proof content should explain IP, sealing and corrosion; cleanroom and slim panel lights need flat surfaces, cleanability and ceiling fit.
- Damp and dusty zones need whole-fixture IP, material and sealing checks.
- Food, pharma and electronics spaces require cleanable surfaces and minimal dust traps.
- Panel lights need grid size, opening, driver location and service access confirmation.
Delivery and Acceptance Documents
- IP and installation documents
- Ceiling or bracket dimensions
- Cleaning method
- Lux and CRI requirements
- Cable sealing inspection
Selection Advice
Confirm site photos, area, mounting height, target illuminance, environment temperature, protection or explosion-proof requirements, existing fixture quantity and control method before final selection.
- IP protection and cleanable construction
- food, pharmaceutical and clean-area requirements
- surface or recessed installation
- damp, dusty or wash-down conditions
Applications
- Industrial factories, warehouses, logistics centers and engineering projects.
- New-build lighting, energy retrofit, illuminance improvement and maintenance cost optimization.
- B2B projects that require consistent product parameters, delivery coordination and technical support.
